Ancoma Scales

Weight Indicators and Displays

At Ancoma Scales, our mission is to provide you with the highest quality Weight Indicators that cater to all your weighing requirements. With years of experience in the industry, we take pride in our expertise, which spans from top-of-the-line customization to offering straightforward weight displays. Whatever your specific needs may be, we have the perfect solution to meet them.

We believe in building lasting relationships with our customers. We don't just stop at the point of purchase; we are here for you as your trusted partner in weighing solutions. With our comprehensive range of Weight Indicators and unparalleled expertise, you can be confident that you are getting the best value for your investment.

Fully Programmable Weight Indicator & Display

Rice Lake 1280

  • Customizable color touchscreen with graphical user interface

  • User-defined softkeys, icons and graphics

  • Tactile keypad for scale operations, numeric entry and navigation

  • On-screen keyboard available during entry mode (or external keyboard)

  • Built-in web server for remote access, systems integration and data monitoring

  • Multi-language operation and text entry

  • Supports eight scales within five different kinds:

  • Analog load cell, multi-range/interval weighing

  • Total scale summing

  • Serial input scales

  • iQUBE² scales

  • Program scales

​

Simple In/Out Weighing Indicator

Rice Lake 720i Digital Weight Indicator

  • The Rice Lake 720i is a Programmable Weight Indicator and Controller that is Ideal for Truck Scale Weighing. Simple In and out weighing allows truck traffic to flow through your site quickly and efficiently.

  • LCD display size: panel mount (3.8 in x 1.2 in), universal (5.3 in x 1.5 in)

  • Four softkeys

  • Truck in/out, 1,000-ID memory (PCE software version)

  • 32 setpoints, 26 configurable types (batch software version)

  • Process control engine ProAction PCE define conditions and actions

​

Built in Ethernet

680 Synergy Series Digital Weight Indicator

  • Bright seven-digit, seven-segment LED display

  • Battery backed time and date

  • Full numeric keypad

  • Three serial ports: two RS-232, one full duplex or half duplex RS-485

  • Numeric keyed entry allowed for tare and setpoint entry

  • Formattable tickets

  • Ethernet TCP/IP

  • USB device

  • Stainless steel IP69K enclosure

  • Four onboard configurable digital I/O points, TTL logic

  • Local/Remote

Intrinsically Safe Weighing

882IS Intrinsically Safe Weight Indicator

The 882IS device offers multiple safety features and flexible power options, including connection to a single AC conduit line or using an FM approved rechargeable battery. Its backlit LCD display ensures excellent visibility and user-friendly operation in all conditions. With a stainless steel enclosure, it provides superior protection for demanding settings. Overall, the 882IS power supply is a reliable and safe solution for a wide range of applications.

Optima OP-900

Simple and Economical

Optima OP-900 Indicator

The Optima OP-900 Indicator is constructed with a Painted Steel, Stainless Steel or IP67 NEMA 4X Washdown Stainless Steel enclosure.

  • 1” LED or LCD display with backlight

  • Units: LED (lb, kg), LCD (lb, kg, oz, lb:oz, g)

  • Color coded check weighing

  • Over/Accept/Under LED lights

  • Washdown version has an IP67 certification to withstand high pressure and high temperature water cleaning to 1450 psi and 176°F/80°C

  • Gross/Tare/Pre-Set Tare/Zero & Multiple Hold functions

  • Count weighing & Accumulation weighing

  • Overload / Underload alarm

Signal Conditioning Transmitter

Rice Lake SCT-2200

Rice Lake offers compact SCT transmitters that cater to PLC systems requiring weight data from a scale. These transmitters provide equivalent signal-conditioning function without the added cost or bulk of a full-size weight indicator/controller. The SCT-2200, designed for DIN Rail mounting within a cabinet or control panel, effectively converts a scale's load cell signals into analog output, serial output, or a specific network protocol.

What sets the SCT-2200 apart from many other signal transmitters is its 0.3-inch weight display, featuring unit and weighing status annunciators, along with push buttons for zero, tare, and setpoint entry. This user-friendly design streamlines scale setup, calibration, and operation, enhancing overall efficiency.

Remote Display 2.5” Compact Model
Remote Display 5” Standard Model
Remote Display 5” with Built-in Traffic Light

Remote Displays

Anyload AH

  • Auto Learn Technology

  • High Brightness LEDs for greater visibility

  • Standard Industrial Communications with Wireless Option

  • Weather Proof Mild Steel Enclosure for Indoor and Outdoor use

  • Standard Pole and Wall Mount Kit

  • 5" Remote Display with Built-in Traffic Light

  • 5" Remote Display Standard Model

  • 2.5" Compact Remote Display Model
